DJI DOCK 2

Easy Remote Operation

The "Drone in a Box" or drone dock is a fully automatic system that houses, charges, and deploys drones without human intervention. It's designed for continuous, scheduled, or on-demand operations, ideal for tasks like inspections, security, surveillance, or data collection.

The entire system including the drone is IP55 rated meaning it is dustproof and waterproof, the DJI Dock 2 can operate in harsh climates and environments. Even in the rain!

IP55 Dustproof and Waterproof

Inbuilt Environmental Monitoring System

DJI Dock 2 integrates multiple sensors, including rainfall, wind speed, and temperature gauges, to perceive real-time weather changes. In conjunction with online weather forecasting, it can provide timely warnings or terminate flight tasks using DJI FlightHub 2 to effectively reduce flight risk.

With a single click or at predetermined intervals, the drone autonomously deploys from the dock, executes its mission, and returns, all without human input. It utilizes cutting-edge image recognition to accurately land, while a comprehensive obstacle sensing system ensures safe navigation around any potential hazards during flight. This blend of technology affords seamless and secure operations.

Fully Autonomous

Key Features

Durability & Weatherproof

>Can operate in rain and dust
>25° to 45° C operating range
>Low Maintenance Requirements

Coverage and Efficiency

>45 Minute Flight Time
>10km Range
>25min Charge Time
>RTK GPS System for 3cm positional accuracy

Fast Deployment

>45 Seconds from a press of a button to being airborne
>Built- In Backup Battery

Easy to use Software

>Fully integrated easy to use cloud based software
>Customisable

What is required to install a DJI DOCK 2 on your property?

Access to Power

A site with 240V AC power, clear sky access, and minimal obstruction. Choose a safe, accessible spot for optimal operation.

Internet Connectivity

We reccomend a minimum of 10mbps upload and download speed. This is to be supplied via a ethernet cable to your existing internet connect.

1.8m x 1.8m Space

At just 35kg and with a compact design, this drone dock can be installed almost anywhere rooftops, backyards, or mountain tops. Bolt it to the ground plug it in and off you go!

One Dock, Two Distinct Drone Options

DJI MATRICE 3D

  • The Matrice 3D features two high-performance cameras: a 20MP wide-angle camera with a large sensor for capturing extensive, detailed images ideal for mapping and area surveys, and a 12MP telephoto camera that allows for detailed zoom-ins on specific areas, suitable for applications where precision is crucial. This configuration supports a variety of uses, particularly in sectors that require high-definition geographic data and detailed inspections from afar.

  • Wide-Angle Camera
    4/3 CMOS
24mm Format Equivalent
20MP Effective Pixels
Mechanical Shutter

    Tele Camera
    1/2-inch CMOS
‌162mm Format Equivalent
12MP Effective Pixels

DJI MATRICE 3TD with Thermal Imaging

  • The Matrice 3TD is equipped with three cameras: a 48MP wide-angle for high-resolution general imaging, a 12MP telephoto for detailed zoom capabilities, and an infrared camera for thermal imaging. This setup enables a wide range of applications from emergency response and infrastructure inspections to environmental monitoring, agriculture, and firefighting, providing essential data for decision-making across various sectors.

  • Wide-Angle Camera
    1/1.32-inch CMOS
24mm Format Equivalent
48MP Effective Pixels

    Tele Camera
    1/2-inch CMOS
‌162mm Format Equivalent
12MP Effective Pixels

    Infrared Camera
    40mm Format Equivalent
Normal Mode: 640×512@30fps
UHR Infrared Image Mode: 1280×1024@30fps
(With the UHR Infrared Image function enabled, the aircraft automatically enables or disables UHR Infrared Image mode according to the ambient light brightness.)
28x Digital Zoom

Available Packages

Once you know which drone model you want pick one of the below packages

Basic Package

Includes drone delivery with a 12-month warranty for manufacturing defects. You handle installation, setup, and operations.

Support & Installation Package

Adds personal delivery, setup, and operational initiation to the Basic Package. Includes 12-month drone insurance.

Comprehensive Package:

Enhances the Support & Installation Package with 2-year insurance and warranty, plus phone support and a day of training for immediate, effective use from day one.

Onboard Camera Monitoring

DJI Dock 2 features an internal and an external fisheye camera to achieve real-time display. Close monitoring within and outside the dock allows the operator to remotely observe weather conditions, environmental circumstances, and the aircraft's takeoff and landing.

Flexibility at Your Fingertips: Manual and Automated Drone Control

Each Dock is equipped with a manual controller for direct drone operation, perfect for setting and recording inspection routes. These can later be automated, allowing the drone to replay these routes at set intervals or operate continuously with autonomous flying and recharging capabilities. This manual control adds flexibility to the automated, cloud-based app functionalities, ensuring comprehensive operational control.

Software

Embrace the future of drone technology with our suite of cloud-based software features, designed to maximize the efficiency and effectiveness of your DJI Dock operations. From generating intricate 3D models for detailed analysis to facilitating precise flight route planning with AI, our tools are crafted to enhance every aspect of your mission. Whether you're conducting remote inspections or managing complex operations, our software ensures you're equipped with the insights and control you need to succeed.
